I am using CarrierWave gem for uploading files and faced a problem of file storage after my application reached a certain number of uploaded files.
I have a User
model and avatar
field for uploading photo of a user.
As my application growing I was getting to many users in system.
So when users count exceeded 32768 in database I started getting an error of "Too many links" in logs.
Something like this
Errno::EMLINK - Too many links - /home/sites/apps/binaryfunction/releases/20140110162610/public/uploads/user/avatar/42435
When I checked file numbers by running following command in system inside
$ cd /home/sites/apps/binaryfunction/releases/20140110162610/public/uploads/user/avatar
$ ls | wc -l
I found that the files count inside my avatar directory has reached 32768
.
What is this error and this number and how can we fix it
I looked over internet and found that there is a maximum limit for files under a directory.
It depends on what filesystem your distribution uses. If you use a newer desktop distribution (recent version of Fedora), you probably use ext4. If you use something older, it is most likely ext3.
So each filesystem has it own number to store file in directory, like
ext2: -> 32768
ext3: -> 31998
ext4: -> 64000
It won't store more files after reaching this number. And start complaining about "Too many links".
CarrierWave gives us default storage path when we generate a uploader
Usually AvatarUploader
looks like
class AvatarUploader < CarrierWave::Uploader::Base
def store_dir
"uploads/#{model.class.to_s.underscore}/#{mounted_as}/#{model.id}"
end
end
According to this all files will be stored in uploads/user/avatar/
directory for a user avatar.
So for user#id 1 it will be like uploads/user/avatar/1.png
.
This will work fine until you reach to maximum number of files(i.e. for ext2 32768).
It means after 32768 your user's avatar will not be saved as your filesystem don't allow more than that inside a dir.
No worry we have a solution here ..yeahhhhh :-)
Paperclip has solved this problem by giving a better storage path for your files by default.
If you have noticed that paperclip generates different directory structure for your files.
An example of file storage path in
paperclip
users/avatar/000/000/013/small/1
You can see here that they have this nested directories “000/000/013”.
They called this id_partition
.
But CarrierWave do not have this nested directory structure by default.
Lets implement this with CarrierWave uploader.
class AvatarUploader < CarrierWave::Uploader::Base
def store_dir
"uploads/#{model.class.to_s.underscore}/#{mounted_as}/#{id_partition}/#{model.id}"
end
private
def id_partition
case id = model.id
when Integer
("%09d" % id).scan(/\d{3}/).join("/")
# can add more checks if you have other id type (i.e. string for monogdb)
else
nil
end
end
end
So using above id_partition
we will be nesting our directories like
"000/000/001"
If our file count reaches 1000 it will create another nested directory like
"000/001/000"
So we have solved this problem for our AvatarUploader
. But what if we have many uploaders in system and we want this in all of our uploaders.
I would suggest to create a BaseUploader
and put this method inside that and all other uploaders can simply inherit BaseUploader
.
class BaseUploader < CarrierWave::Uploader::Base
def store_dir
"uploads/#{model.class.to_s.underscore}/#{mounted_as}/#{id_partition}/#{model.id}"
end
private
def id_partition
case id = model.id
when Integer
("%09d" % id).scan(/\d{3}/).join("/")
else
nil
end
end
end
And AvatarUploader
will become
class AvatarUploader < BaseUploader
end
To verify this id_partition
work you can simply write a test something like
require 'spec_helper'
describe BaseUploader do
describe 'store_dir' do
it 'should have id_partition included' do
model_id = 123
uploader = BaseUploader.new
model = double(id: model_id)
uploader.stub(:model).and_return(model)
expect(uploader.store_dir).to match(/000\/000\/#{model_id}\/#{model_id}/)
end
it 'should have another id_partition when id is higher' do
model_id = 1001
uploader = BaseUploader.new
model = double(id: model_id)
uploader.stub(:model).and_return(model)
expect(uploader.store_dir).to match(/000\/001\/001\//)
end
end
end
By doing this you can easily solve problem of "Too many links" with CarrierWave and avoid having too many files inside one folder.
I know it is a bit hard to migrate all your uploads when you reach to this number of filess so it is better to have this in first place to avoid problems in future.
I hope this article will be helpful to you.
